Intel Core i9-13900KS is a high-performance desktop processor with 24 cores, including 8 P-cores and 16 E-cores, as well as 32 threads. The processor is equipped with an integrated Intel UHD Graphics 770. Its hybrid architecture prioritizes and distributes workloads for optimized performance. With up to 6.0 GHz unlocked and 36M Cache, Intel Core i9-13900KS is compatible with Intel 600 series and 700 series chipset-based motherboards. It also features Turbo Boost Max Technology 3.0, PCIe 5.0 and 4.0 support, and Intel Optane Memory support.
Intel Core i9-13900KS Details
The Intel Core i9 13900KS processor is part of Intel’s 13th generation of processors. It has a base frequency of 2.40GHz and can reach a turbo frequency max of 4.30GHz. The processor has 24 cores and 32 threads, which makes it a powerful choice for demanding workloads. It also has an intelligent cache of 36MB and an L2 cache of 32 MB.
The CPU is compatible with up to 128GB of memory and supports DDR5 and DDR4 memory types, with a maximum speed of 5600 MT/s for DDR5 and 3200 MT/s for DDR4. It has two memory channels and supports ECC memory. The Intel Core i9 13900KS processor comes with Intel UHD Graphics 770, which has a base frequency 300MHz and can reach a dynamic frequency max of 1.65GHz. The graphics card can handle resolutions of up to 4096 x 2160 @ 60Hz (HDMI), 7680 x 4320 @ 60Hz (DP), and 5120 x 3200 @ 120Hz (eDP-Integrated Flat Panel).
Intel Core i9-13900KS supports DirectX 12 and OpenGL 4.5. This processor is compatible with LGA1700 sockets and has a processor base power of 150W and a maximum turbo power of 253W. It also supports OpenCL 3.0 and includes Intel Clear Video HD Technology, Intel Deep Learning Boost (Intel DL Boost), Intel Speed Shift Technology, Intel Thermal Velocity Boost, and Enhanced Intel SpeedStep Technology. The Intel Core i9 13900KS processor is compatible with Intel B760, Intel H770, and Intel Z790.
Specifications
| Processor Cores (P-cores + E-cores) | 24 cores (8 P-cores + 16 E-cores) |
| Processor Threads | 32 |
| P-core / E-core Base Frequency (GHz) | 3.2 / 2.4 |
| Max Frequency GHz (not overclocked) | 6.0 GHz |
| Intel Smart Cache / Total L2 Cache | 36MB / 32MB |
| Processor Base Power / Maximum Turbo Power | 150W / 253W |
| Memory Types and Speed | DDR5 5600 MT/s, DDR4 3200MT/s |
| Max of Memory Channels / Max Memory Bandwidth | 2 / 89GB |
| Max Memory Size (dependent on memory type) | 128 GB |
| Onboard Processor Graphics | Intel UHD Graphics 770 |
| Graphics Base / Max Dynamic Frequency | 300 MHz / 1.65 GHz |
| DMI Revision/ Max of DMI Lanes | 4.0 / 8 |
| Total CPU PCI Express Lanes | 20 |
| Chipset Compatibility and Socket | Intel 600 and 700 Series Chipset, LGA1700 Socket |
| Intel® Gaussian & Neural Accelerator | 3.0 |
UserBenchmark (Release date ≈ Q4 2022)
The Intel Core i9-13900KS has performed exceptionally well, achieving a peak score that is 30.9% higher. Its impressive performance places it close to the top of the comparison list.
